Description
Product Overview:
The VEW 2307E Desktop Microcomputer-Controlled Tensile Testing Machine is a compact and versatile device designed with a lightweight aluminum structure. Its sleek design and small footprint make it easy to position and move, making it ideal for quality control on production lines. The machine’s high-precision capabilities allow it to test both metallic and non-metallic materials with loads up to 2kN.
This model is computer-controlled and generates detailed testing reports. Its refined exterior features a high-quality baked varnish finish, combining durability with an elegant appearance.
Compliance and Standards
Compliance and Standards:
The VEW 2307E adheres to the following standards:
- GB/T16491-1996 Electronic Universal Testing Machine
- ASTM E4
- ISO7500-1
- EN10002-2
- BS1610
- DIN51221
It also meets industry standards for glove testing.
Application
This testing machine is suitable for evaluating the performance of flexible materials in various tests, including:
- Tensile strength
- Tear resistance
- Adhesive strength
- 90° and 180° peel tests
It is widely used for materials such as rubber, plastic, plastic films, and more. The machine is equipped with an extensometer to measure large material deformations accurately.
Machine Dimensions and Power
- Dimensions (L x W x H): 650 x 360 x 2100mm (including operating table height)
- Drive System: Panasonic AC Servo Motor with high-precision ball screw
- Power Supply: 220V, 50Hz
- Power Consumption: 0.2kW (varies based on motor capacity)
- Machine Weight: Approx. 160kg
- Measurement Units: kgf, N, lb, Ton
The VEW 2307E delivers exceptional performance, reliability, and precision, making it an excellent choice for material testing across various industries.
